Battery Runtime Calculator

Estimate how long your battery can power a load using capacity (Ah), voltage (V), and power consumption (W).

Enter Battery & Load Details

Use 90% as a typical estimate for AC loads. For a DC load connected directly to the battery, use 100% here; wiring and battery losses may still apply.
Estimate: usable battery energy (Ah × V × DoD fraction) × conversion efficiency ÷ load power (W). This assumes nominal voltage and rated capacity; actual runtime varies with discharge rate, temperature, battery age, voltage cut-off and wiring losses.
Related Solar Calculators:
• Array Power to Energy/Day
• Battery Autonomy Day Without Sun
• Ground vs Rooftop
• Full Off-Grid System
• Temperature Coefficient Loss

How to Estimate Battery Runtime from Capacity, Voltage, and Load Power

The battery runtime calculator helps you determine how long a battery can power your devices or appliances based on its capacity (Ah), voltage (V), and the power draw of the connected load (W). This is a critical step when designing solar systems, backup setups, or portable power solutions — ensuring you don’t run out of energy mid-operation.

Understanding the Basic Battery Runtime Formula

The core relationship between capacity, voltage, and load power is simple:

Runtime (hours) ≈ (Battery Capacity (Ah) × Nominal Voltage (V) × DoD fraction × Conversion efficiency) ÷ Load Power (W)

This estimate includes the conversion-efficiency value entered above. For an AC load, inverter efficiency is commonly less than 100%; for a DC load connected directly to the battery, set conversion efficiency to 100%. Cable resistance, temperature, battery age, discharge rate and low-voltage cut-off can further change actual runtime. For example, if you have a 100Ah 12V battery powering a 100W load with 80% depth of discharge, your usable energy is:

100Ah × 12V × 0.8 × 0.9 = 864Wh estimated energy delivered. At a 100W AC load, estimated runtime = 864 ÷ 100 = 8.64 hours (about 8.6 hours).

Step-by-Step: Using the Battery Runtime Calculator

  1. Enter battery capacity in amp-hours (Ah). This value is often printed on your battery’s label.
  2. Enter voltage — typically 12V, 24V, or 48V, depending on your system.
  3. Input load power in watts (W). This can be the consumption of your appliance, inverter, or full system.
  4. Adjust the Depth of Discharge (DoD %) to match how much of the battery you plan to use. Lithium batteries usually allow 80–90%, while lead-acid types prefer 50% or less.
  5. Enter the conversion efficiency, then click “Calculate Runtime.” The tool estimates runtime in hours and days and displays relevant usage notes.

The calculator displays a caution when the selected depth of discharge is above 90%. Follow your battery manufacturer’s recommended operating limits; the appropriate DoD depends on battery chemistry and model.

What Affects Actual Battery Runtime?

Even with the same rated capacity, real-world runtime can differ due to several variables:

  • Discharge Rate (C-rate): Higher current draw reduces usable capacity, especially in lead-acid batteries.
  • Battery Temperature: Cold environments can reduce effective capacity by 20–30%.
  • Inverter Efficiency: DC–AC conversion losses can be 5–15% depending on the inverter quality.
  • Wiring & Voltage Drop: Undersized cables cause losses that shorten runtime.
  • Battery Aging: As a battery cycles over time, capacity slowly declines — sometimes 10–20% within the first few years.

Example Runtime Calculations

Here are a few quick scenarios you can try in the calculator:

  • 12V 100Ah battery + 100W AC load: ≈ 8.6 hours at 80% DoD and 90% efficiency
  • 24V 200Ah battery + 400W AC load: ≈ 8.6 hours at 80% DoD and 90% efficiency
  • 12V 50Ah battery + 60W AC load: ≈ 7.2 hours at 80% DoD and 90% efficiency

Notice how voltage and capacity scale proportionally with runtime — doubling either effectively doubles your operating time, assuming the same load.

How Depth of Discharge (DoD) Impacts Battery Life

The deeper you discharge a battery, the shorter its lifespan becomes. A lithium iron phosphate (LiFePO₄) battery cycled at 80% DoD may last over 3,000 cycles, while the same battery cycled at 100% may drop to 2,000 cycles or less.

For lead-acid batteries, the effect is more pronounced — using more than 50% of the capacity regularly can cut its usable life by half. That’s why the calculator includes a DoD input, letting you compare different depth-of-discharge values to find a balance between runtime and longevity.

Improving Battery Runtime in Practical Systems

To extend runtime and optimize performance:

  • Use higher-voltage systems (24V or 48V) to reduce current and minimize voltage drop.
  • Add batteries in parallel to increase total amp-hours (Ah).
  • Ensure efficient inverters rated 90% or higher.
  • Keep battery terminals clean and cables thick enough for the load current.
  • Keep batteries within their ideal temperature range (20–30°C).

Choosing the Right Battery for Your Runtime Needs

Selecting the correct battery depends on your target runtime and daily usage pattern. For example, a small off-grid cabin running lights and a fan for 10 hours might need a 12V 100Ah battery. In contrast, a solar-powered workstation running a 300W inverter for 8 hours may need a 24V 200Ah setup.

If you need both runtime and autonomy (multiple days of storage), consider using the Battery Capacity Needed for X Hours Runtime Calculator to plan your full energy storage bank.

Key Takeaways

  • Battery runtime depends on usable watt-hours (Wh) divided by load watts (W).
  • Include DoD limits and inverter losses for realistic results.
  • Use parallel configurations to extend runtime without increasing voltage.
  • Keep discharge shallow to preserve battery cycle life.

The SolarMathLab Battery Runtime Calculator is designed for quick, practical estimation — perfect for solar engineers, DIY installers, and anyone sizing a power backup system. Whether you’re calculating how long a portable power station can run a fridge or how much storage your solar setup needs, this tool gives you a fast, science-based answer.
